SN74HC174NSR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Cut Tape (CT) 74HC174 e4 74HC flip flop 10.3mm 2V 27ns @ 6V 50pF 50MHz
PDF
/
Buying Options
Total Price: USD $0.75
Unit Price: USD $0.748
≥1 USD $0.748
≥10 USD $0.6688
≥100 USD $0.634656
≥500 USD $0.521312
≥1000 USD $0.487274
≥3000 USD $0.430619
Inventory: 1118
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.95mm
Width 5.3mm
Length 10.3mm
Height 2mm
Technical
Max Frequency@Nom-Sup 25000000Hz
Clock Edge Trigger Type Positive Edge
fmax-Min 29 MHz
Number of Input Lines 3
Power Supply Current-Max (ICC) 0.08mA
Input Capacitance 3pF
Trigger Type Positive Edge
Prop. Delay@Nom-Sup 40 ns
Max Propagation Delay @ V, Max CL 27ns @ 6V, 50pF
Number of Bits per Element 6
Max I(ol) 0.0052 A
Current - Output High, Low 5.2mA 5.2mA
Current - Quiescent (Iq) 8μA
Logic Function D-Type, Flip-Flop
Family HC/UH
Turn On Delay Time 14 ns
Propagation Delay 200 ns
Clock Frequency 50MHz
Output Current 5.2mA
Load Capacitance 50pF
Number of Circuits 7
Supply Voltage-Min (Vsup) 2V
Supply Voltage-Max (Vsup) 6V
Polarity Non-Inverting
Number of Elements 1
Operating Supply Voltage 5V
Output Type Non-Inverted
Function Master Reset
Base Part Number 74HC174
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Packing Method TR
Subcategory FF/Latches
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type D-Type
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74HC
Packaging Cut Tape (CT)
Operating Temperature -40°C~85°C TA
Physical
Weight 200.686274mg
Number of Pins 16
Package / Case 16-SOIC (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
Alternative Model
