SN74HC174DG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Lead Free D FLIP-FLOP CMOS Positive Edge Flip Flop 85C 5.2mA 50pF 6V
PDF
/
Buying Options
Total Price: USD $0.14
Unit Price: USD $0.140899
≥1 USD $0.140899
≥200 USD $0.054526
≥500 USD $0.05261
≥1000 USD $0.051663
Inventory: 1124
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case SOIC
Number of Pins 16
Weight 141.690917mg
Technical
JESD-609 Code e4
Moisture Sensitivity Level (MSL) 1
Number of Terminations 16
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Subcategory FF/Latches
Packing Method TUBE
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Frequency 50MHz
Pin Count 16
Operating Supply Voltage 5V
Number of Elements 1
Polarity Non-Inverting
Temperature Grade INDUSTRIAL
Max Supply Voltage 6V
Min Supply Voltage 2V
Load Capacitance 50pF
Current - Output 5.2mA
Propagation Delay 160 ns
Turn On Delay Time 14 ns
Family HC/UH
Logic Function D-Type, Flip-Flop
Logic IC Type D FLIP-FLOP
Max I(ol) 0.004 A
Number of Bits per Element 6
High Level Output Current -5.2mA
Low Level Output Current 5.2mA
fmax-Min 29 MHz
Clock Edge Trigger Type Positive Edge
Dimensions
Height 1.58mm
Length 9.9mm
Width 3.91mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
