SN74BCT574DW
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tube 74BCT574 e4 74BCT flip flop 12.8mm 8.6ns @ 5V 50pF 77MHz 8.6ns
PDF
/
Buying Options
Total Price: USD $2.18
Unit Price: USD $2.178101
≥1 USD $2.178101
≥200 USD $0.842882
≥500 USD $0.813998
≥1000 USD $0.799556
Inventory: 5715
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 2.35mm
Width 7.5mm
Length 12.8mm
Height 2.65mm
Technical
Max Frequency@Nom-Sup 77000000Hz
Translation N/A
Clock Edge Trigger Type Positive Edge
Count Direction UNIDIRECTIONAL
Number of Output Lines 3
Power Supply Current-Max (ICC) 62mA
Input Capacitance 5.5pF
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 8.6ns @ 5V, 50pF
Max I(ol) 0.064 A
Current - Output High, Low 15mA 64mA
Current - Quiescent (Iq) 8mA
Logic Function D-Type, Flip-Flop
Family BCT/FBT
Turn On Delay Time 6.5 ns
Propagation Delay 8.6 ns
Clock Frequency 77MHz
Number of Bits 8
Output Current 64mA
Number of Ports 2
Load Capacitance 50pF
Number of Circuits 8
Power Supplies 5V
Polarity Non-Inverting
Number of Elements 1
Operating Supply Voltage 5V
Output Type Tri-State, Non-Inverted
Function Standard
Base Part Number 74BCT574
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology BICMOS
Subcategory FF/Latches
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type D-Type
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74BCT
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Weight 500.709277mg
Number of Pins 20
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
