SN74BCT574DBRE4
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Not Qualified Standard D-Type BICMOS Flip Flop 0C~70C TA 8mA 5.5pF 4.5V~5.5V
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.07445
≥1 USD $1.07445
≥10 USD $0.8816
≥100 USD $0.85405
≥500 USD $0.8265
≥1000 USD $0.79895
Inventory: 498
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 7.2mm
Height Seated (Max) 2mm
Technical
Max Frequency@Nom-Sup 77000000Hz
Clock Edge Trigger Type Positive Edge
Number of Output Lines 3
Number of Input Lines 8
Input Capacitance 5.5pF
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 8.6ns @ 5V, 50pF
Max I(ol) 0.064 A
Current - Output High, Low 15mA 64mA
Current - Quiescent (Iq) 8mA
Logic Function D-Type, Flip-Flop
Family BCT/FBT
Turn On Delay Time 6.5 ns
Propagation Delay 8.6 ns
Clock Frequency 77MHz
Number of Bits 8
Number of Ports 2
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 4.5V
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Polarity Non-Inverting
Number of Elements 1
Output Type Tri-State, Non-Inverted
Qualification Status Not Qualified
Function Standard
Base Part Number 74BCT574
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology BICMOS
Packing Method TAPE AND REEL
Subcategory FF/Latches
Type D-Type
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series 74BCT
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 20
Package / Case 20-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
