SN74AS874DWR
RoHS
RoHS compliant
RoHS compliantPackage 24-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Not Qualified Master Reset D-Type TTL Flip Flop 0C~70C TA 133mA 50pF 4.5V~5.5V
PDF
/
Inventory: 1622
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 24-SOIC (0.295, 7.50mm Width)
Number of Pins 24
Technical
Operating Temperature 0°C~70°C TA
Packaging Tape & Reel (TR)
Series 74AS
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
Type D-Type
Additional Feature WITH CLEAR
Subcategory FF/Latches
Packing Method TAPE AND REEL
Technology TTL
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74AS874
Function Master Reset
Qualification Status Not Qualified
Output Type Tri-State, Non-Inverted
Number of Elements 2
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Load Capacitance 50pF
Number of Ports 2
Output Current 48mA
Clock Frequency 125MHz
Propagation Delay 10.5 ns
Turn On Delay Time 3 ns
Family AS
Logic Function D-Type, Flip-Flop
Current - Quiescent (Iq) 133mA
Output Characteristics 3-STATE
Current - Output High, Low 15mA 48mA
Number of Bits per Element 4
Max Propagation Delay @ V, Max CL 10.5ns @ 5V, 50pF
Trigger Type Positive Edge
Number of Output Lines 1
Clock Edge Trigger Type Positive Edge
Dimensions
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
