SN74AS574N
RoHS
RoHS compliant
RoHS compliantPackage 20-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tube 74AS574 e4 74AS flip flop 24.33mm 9ns @ 5V 50pF 90MHz 9ns
PDF
/
Buying Options
Total Price: USD $2.79
Unit Price: USD $2.7896
≥1 USD $2.7896
≥10 USD $2.50844
≥100 USD $2.3716
≥500 USD $2.055416
≥1000 USD $1.949974
≥3000 USD $1.855709
Inventory: 113
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case 20-DIP (0.300, 7.62mm)
Number of Pins 20
Weight 1.1991g
Mount Through Hole
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
Series 74AS
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Type D-Type
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory FF/Latches
Technology TTL
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Supply Voltage 5V
Terminal Pitch 2.54mm
Base Part Number 74AS574
Function Standard
Output Type Tri-State, Non-Inverted
Operating Supply Voltage 5V
Number of Elements 1
Polarity Non-Inverting
Power Supplies 5V
Number of Circuits 8
Load Capacitance 50pF
Number of Ports 2
Output Current 48mA
Number of Bits 8
Clock Frequency 90MHz
Propagation Delay 9 ns
Turn On Delay Time 3 ns
Family AS
Logic Function D-Type, Flip-Flop
Current - Quiescent (Iq) 116mA
Current - Output High, Low 15mA 48mA
Max Propagation Delay @ V, Max CL 9ns @ 5V, 50pF
Trigger Type Positive Edge
Number of Input Lines 3
Count Direction UNIDIRECTIONAL
Clock Edge Trigger Type Positive Edge
Max Frequency@Nom-Sup 90000000Hz
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
Dimensions
Height 5.08mm
Length 24.33mm
Width 6.35mm
Thickness 4.57mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
