SN74AS374DWR
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Not Qualified Standard D-Type TTL Flip Flop 0C~70C TA 120mA 50pF 4.5V~5.5V
PDF
/
Buying Options
Total Price: USD $1.81
Unit Price: USD $1.8128
≥1 USD $1.8128
Inventory: 7822
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Height Seated (Max) 2.65mm
Technical
Clock Edge Trigger Type Positive Edge
Number of Input Lines 3
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 9ns @ 5V, 50pF
Number of Bits per Element 8
Current - Output High, Low 15mA 48mA
Current - Quiescent (Iq) 120mA
Logic Function D-Type, Flip-Flop
Family AS
Turn On Delay Time 3 ns
Propagation Delay 9 ns
Clock Frequency 125MHz
Output Current 48mA
Number of Ports 2
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 4.5V
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Polarity Non-Inverting
Number of Elements 1
Output Type Tri-State, Non-Inverted
Qualification Status Not Qualified
Function Standard
Base Part Number 74AS374
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology TTL
Packing Method TAPE AND REEL
Subcategory FF/Latches
Type D-Type
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series 74AS
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 20
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
