SN74AS175BD
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tube 74AS175 e4 74AS flip flop 9.9mm 10ns @ 5V 50pF 100MHz 10ns
PDF
/
Buying Options
Total Price: USD $4.54
Unit Price: USD $4.5353
≥1 USD $4.5353
≥10 USD $3.72115
≥100 USD $3.60525
≥500 USD $3.4884
≥1000 USD $3.3725
Inventory: 7157
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Weight 141.690917mg
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
Series 74AS
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Termination SMD/SMT
Type D-Type
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory FF/Latches
Technology TTL
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74AS175
Function Master Reset
Qualification Status Not Qualified
Output Type Differential
Operating Supply Voltage 5V
Number of Elements 1
Polarity Non-Inverting
Power Supplies 5V
Number of Circuits 7
Load Capacitance 50pF
Output Current 20mA
Clock Frequency 100MHz
Propagation Delay 10 ns
Turn On Delay Time 3 ns
Family AS
Logic Function D-Type, Flip-Flop
Current - Quiescent (Iq) 34mA
Current - Output High, Low 2mA 20mA
Number of Bits per Element 4
Max Propagation Delay @ V, Max CL 10ns @ 5V, 50pF
Trigger Type Positive Edge
Number of Input Lines 3
Number of Output Lines 2
Clock Edge Trigger Type Positive Edge
Dimensions
Height 1.75mm
Length 9.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
