SN74AHC74N
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tube 74AHC74 e4 74AHC flip flop 19.3mm 2V 9.3ns @ 5V 50pF 115MHz
PDF
/
Buying Options
Total Price: USD $0.88
Unit Price: USD $0.88
≥1 USD $0.88
≥10 USD $0.78408
≥100 USD $0.744128
≥500 USD $0.611248
≥1000 USD $0.571366
≥3000 USD $0.504926
Inventory: 551
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 3.9mm
Width 6.35mm
Length 19.3mm
Height 5.08mm
Technical
Max Frequency@Nom-Sup 75000000Hz
Clock Edge Trigger Type Positive Edge
Number of Input Lines 4
Input Capacitance 2pF
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 9.3ns @ 5V, 50pF
Number of Bits per Element 1
Max I(ol) 0.008 A
Current - Output High, Low 8mA 8mA
Current - Quiescent (Iq) 2μA
Logic Function AND, D-Type, Flip-Flop
Family AHC/VHC/H/U/V
Turn On Delay Time 1 ns
Propagation Delay 18 ns
Clock Frequency 115MHz
Output Current 8mA
Load Capacitance 50pF
Number of Channels 2
Supply Voltage-Min (Vsup) 2V
Polarity Non-Inverting
Output Type Differential
Output Voltage 5.5V
Function Set(Preset) and Reset
Base Part Number 74AHC74
Supply Voltage 3.3V
Terminal Position DUAL
Voltage - Supply 2V~5.5V
Technology CMOS
Subcategory FF/Latches
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type D-Type
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series 74AHC
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Weight 927.99329mg
Number of Pins 14
Package / Case 14-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
