SN74AHC574PWG4
RoHS
/
Package TSSOP
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
IC D-TYPE POS TRG SNGL 20TSSOP
PDF
/
Inventory: 5708
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case TSSOP
Number of Pins 20
Weight 76.997305mg
Technical
JESD-609 Code e4
Moisture Sensitivity Level (MSL) 1
Number of Terminations 20
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Subcategory FF/Latches
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Frequency 115MHz
Pin Count 20
Polarity Non-Inverting
Temperature Grade AUTOMOTIVE
Number of Circuits 8
Max Supply Voltage 5.5V
Min Supply Voltage 2V
Load Capacitance 50pF
Number of Ports 2
Current - Output 8mA
Number of Bits 8
Propagation Delay 16.7 ns
Turn On Delay Time 1 ns
Family AHC/VHC/H/U/V
Logic Function D-Type, Flip-Flop
Logic IC Type BUS DRIVER
High Level Output Current -8mA
Low Level Output Current 8mA
Number of Input Lines 3
Number of Output Lines 1
Clock Edge Trigger Type Positive Edge
Dimensions
Length 6.5mm
Width 4.4mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
