SN74ABT534ADWR
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tape & Reel (TR) 74ABT534 e4 74ABT flip flop 12.8mm 6.7ns @ 5V 50pF 175MHz 7.6ns
PDF
/
Buying Options
Total Price: USD $0.75
Unit Price: USD $0.746691
≥1 USD $0.746691
≥100 USD $0.56376
≥250 USD $0.411022
≥1000 USD $0.289789
Inventory: 1399
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 2.35mm
Width 7.5mm
Length 12.8mm
Height 2.65mm
Technical
Translation N/A
Clock Edge Trigger Type Positive Edge
Count Direction UNIDIRECTIONAL
Number of Output Lines 3
Input Capacitance 3.5pF
Trigger Type Positive Edge
Prop. Delay@Nom-Sup 7.6 ns
Max Propagation Delay @ V, Max CL 6.7ns @ 5V, 50pF
Max I(ol) 0.064 A
Current - Output High, Low 32mA 64mA
Current - Quiescent (Iq) 250μA
Logic Function D-Type, Flip-Flop
Family ABT
Turn On Delay Time 4.5 ns
Propagation Delay 6.7 ns
Clock Frequency 175MHz
Number of Bits 8
Output Current 64mA
Number of Ports 2
Load Capacitance 50pF
Number of Circuits 8
Power Supplies 5V
Polarity Inverting
Number of Elements 1
Operating Supply Voltage 5V
Output Type Tri-State, Inverted
Qualification Status Not Qualified
Function Standard
Base Part Number 74ABT534
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology BICMOS
Packing Method TR
Subcategory FF/Latches
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type D-Type
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74ABT
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Weight 500.709277mg
Number of Pins 20
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 6 Weeks
Alternative Model
