CY74FCT823CTSOCT
RoHS
RoHS compliant
RoHS compliantPackage 24-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Lead Free Not Qualified Master Reset D-Type Flip Flop -40C~85C TA 200muA 5pF 4.75V~5.25V
PDF
/
Buying Options
Total Price: USD $0.61
Unit Price: USD $0.608353
≥1 USD $0.608353
≥10 USD $0.573914
≥100 USD $0.541424
≥500 USD $0.510777
≥1000 USD $0.481864
Inventory: 6361
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Height Seated (Max) 2.65mm
Technical
Max Frequency@Nom-Sup 83300000Hz
Clock Edge Trigger Type Positive Edge
Number of Input Lines 9
Input Capacitance 5pF
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 12.5ns @ 5V, 300pF
Max I(ol) 0.064 A
Current - Output High, Low 32mA 64mA
Output Characteristics 3-STATE
Current - Quiescent (Iq) 200μA
Logic Function D-Type, Flip-Flop
Family FCT
Turn On Delay Time 6 ns
Propagation Delay 12.5 ns
Number of Bits 9
Output Current 64mA
Number of Ports 2
Load Capacitance 50pF
Power Supplies 5V
Polarity Non-Inverting
Number of Elements 1
Operating Supply Voltage 5V
Output Type Tri-State, Non-Inverted
Qualification Status Not Qualified
Function Master Reset
Base Part Number 74FCT823
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Supply Voltage 5V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology CMOS
Packing Method TAPE AND REEL
Subcategory FF/Latches
Type D-Type
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series 74FCT
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Weight 624.398247mg
Number of Pins 24
Package / Case 24-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
