CD74HCT173MT
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Lead Free Not Qualified Master Reset D-Type Flip Flop -55C~125C TA 6mA 6mA 10pF 4.5V~5.5V
PDF
/
Buying Options
Total Price: USD $1.17
Unit Price: USD $1.16668
≥1 USD $1.16668
≥10 USD $1.100638
≥100 USD $1.038342
≥500 USD $0.979563
≥1000 USD $0.924119
Inventory: 2543
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Length 9.9mm
Technical
Clock Edge Trigger Type Positive Edge
Number of Output Lines 3
Input Capacitance 10pF
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 40ns @ 4.5V, 50pF
Max I(ol) 0.006 A
Current - Output High, Low 6mA 6mA
Logic Function D-Type, Flip-Flop
Family HCT
Turn On Delay Time 17 ns
Quiescent Current 8μA
Propagation Delay 40 ns
Clock Frequency 60MHz
Number of Bits 4
Output Current 6mA
Load Capacitance 50pF
Number of Circuits 4
Power Supplies 5V
Polarity Non-Inverting
Number of Elements 1
Operating Supply Voltage 5V
Output Type Tri-State, Non-Inverted
Qualification Status Not Qualified
Function Master Reset
Base Part Number 74HCT173
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Packing Method TAPE AND REEL
Subcategory FF/Latches
Additional Feature WITH DUAL OUTPUT ENABLE
Type D-Type
Termination SMD/SMT
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series 74HCT
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C TA
Physical
Weight 141.690917mg
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
