CD74HC574ME4

Texas Instruments
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description Rail/Tube e4 Non-Inverting HC/UH flip flop 500.709277mg 60MHz 15ns 6V
PDF
/
Inventory: 3326
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Plating Gold
Mount Surface Mount
Package / Case SOIC
Number of Pins 20
Weight 500.709277mg

Technical

Packaging Rail/Tube
JESD-609 Code e4
Moisture Sensitivity Level (MSL) 1
Number of Terminations 20
ECCN Code EAR99
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Subcategory Bus Driver/Transceiver
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 4.5V
Frequency 60MHz
Pin Count 20
Number of Elements 1
Polarity Non-Inverting
Temperature Grade MILITARY
Max Supply Voltage 6V
Min Supply Voltage 2V
Load Capacitance 50pF
Number of Ports 2
Current - Output 7.8mA
Propagation Delay 250 ns
Quiescent Current 8μA
Turn On Delay Time 15 ns
Family HC/UH
Logic Function D-Type, Flip-Flop
Logic IC Type BUS DRIVER
Max I(ol) 0.006 A
Number of Bits per Element 8
High Level Output Current -7.8mA
Low Level Output Current 7.8mA
Number of Output Lines 3
Clock Edge Trigger Type Positive Edge

Dimensions

Height Seated (Max) 2.65mm
Width 7.5mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
