CD74FCT273E

Texas Instruments
RoHS
RoHS RoHS compliant
Package 20-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description Lead Free Master Reset D-Type BICMOS Flip Flop 0C~70C TA 15mA 48mA 50pF 4.75V~5.25V
PDF
/
Buying Options
Total Price: USD $0.45
Unit Price: USD $0.4488
≥1 USD $0.4488
Inventory: 19026
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)

Physical

Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole
Package / Case 20-DIP (0.300, 7.62mm)
Number of Pins 20
Weight 1.1991g

Technical

Operating Temperature 0°C~70°C TA
Packaging Tube
Series 74FCT
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Type D-Type
Subcategory FF/Latches
Technology BICMOS
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Supply Voltage 5V
Terminal Pitch 2.54mm
Base Part Number 74FCT273
Function Master Reset
Output Type Non-Inverted
Operating Supply Voltage 5V
Number of Elements 1
Polarity Non-Inverting
Power Supplies 5V
Number of Circuits 8
Load Capacitance 50pF
Output Current 48mA
Number of Bits 8
Clock Frequency 70MHz
Propagation Delay 13 ns
Quiescent Current 8μA
Turn On Delay Time 7 ns
Family FCT
Logic Function D-Type, Flip-Flop
Current - Output High, Low 15mA 48mA
Max Propagation Delay @ V, Max CL 7ns @ 5V, 50pF
Trigger Type Positive Edge
fmax-Min 70 MHz
Clock Edge Trigger Type Positive Edge
Max Frequency@Nom-Sup 70000000Hz

Dimensions

Height 5.08mm
Length 24.33mm
Width 6.35mm
Thickness 4.57mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
