CD74AC112M96
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tape & Reel (TR) 74AC112 e4 74AC flip flop 9.9mm 10.3ns @ 5V 50pF 100MHz 129ns
PDF
/
Buying Options
Total Price: USD $0.6
Unit Price: USD $0.5984
≥1 USD $0.5984
≥10 USD $0.528
≥100 USD $0.495968
≥500 USD $0.4048
≥1000 USD $0.375971
≥3000 USD $0.319968
Inventory: 1242
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Weight 141.690917mg
Technical
Operating Temperature -55°C~125°C TA
Packaging Tape & Reel (TR)
Series 74AC
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Type JK Type
Subcategory FF/Latches
Packing Method TR
Technology CMOS
Voltage - Supply 1.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Base Part Number 74AC112
Function Set(Preset) and Reset
Output Type Differential
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 3.3/5V
Number of Circuits 2
Load Capacitance 50pF
Output Current 24mA
Clock Frequency 100MHz
Propagation Delay 129 ns
Quiescent Current 4μA
Turn On Delay Time 2.6 ns
Family AC
Logic Function AND, Flip-Flop, JK-Type
Current - Output High, Low 24mA 24mA
Number of Bits per Element 1
Max Propagation Delay @ V, Max CL 10.3ns @ 5V, 50pF
Trigger Type Negative Edge
Input Capacitance 10pF
Schmitt Trigger No
Power Supply Current-Max (ICC) 0.04mA
Clock Edge Trigger Type Negative Edge
Dimensions
Height 1.75mm
Length 9.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
