CD4076BM96G4
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Lead Free Not Qualified Reset D-Type Flip Flop -55C~125C TA 20muA 5pF 3V~18V
PDF
/
Inventory: 1208
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Weight 141.690917mg
Technical
Operating Temperature -55°C~125°C TA
Packaging Tape & Reel (TR)
Series 4000B
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Type D-Type
Subcategory FF/Latches
Packing Method TAPE AND REEL
Technology CMOS
Voltage - Supply 3V~18V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 5V
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CD4076
Function Reset
Qualification Status Not Qualified
Output Type Tri-State, Non-Inverted
Number of Elements 1
Polarity Non-Inverting
Supply Voltage-Min (Vsup) 3V
Load Capacitance 50pF
Number of Bits 4
Clock Frequency 16MHz
Propagation Delay 600 ns
Turn On Delay Time 60 ns
Current - Quiescent (Iq) 20μA
Output Characteristics 3-STATE
Current - Output High, Low 6.8mA 6.8mA
Max Propagation Delay @ V, Max CL 180ns @ 15V, 50pF
Trigger Type Positive Edge
Input Capacitance 5pF
Number of Output Lines 4
fmax-Min 8 MHz
Clock Edge Trigger Type Positive Edge
Max Frequency@Nom-Sup 3000000Hz
Dimensions
Length 9.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
