CD40175BMTE4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
IC D-TYPE POS TRG SNGL 16SOIC
PDF
/
Inventory: 8484
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Gold
Mount Surface Mount
Package / Case SOIC
Number of Pins 16
Weight 141.690917mg
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e4
Moisture Sensitivity Level (MSL) 1
Number of Terminations 16
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Subcategory FF/Latches
Packing Method TAPE AND REEL
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Frequency 14MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 16
Number of Outputs 8
Qualification Status Not Qualified
Number of Elements 1
Polarity Non-Inverting
Temperature Grade MILITARY
Max Supply Voltage 18V
Min Supply Voltage 3V
Load Capacitance 50pF
Propagation Delay 400 ns
Quiescent Current 20μA
Turn On Delay Time 70 ns
Logic Function D-Type
Logic IC Type D FLIP-FLOP
Number of Bits per Element 4
High Level Output Current -4.2mA
Low Level Output Current 6.8mA
fmax-Min 6.5 MHz
Clock Edge Trigger Type Positive Edge
Dimensions
Length 9.9mm
Width 3.9mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
