74VHC174TTR
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Cut Tape (CT) 74VHC174 e4 74VHC flip flop 5mm 2V 120MHz 14.5ns
PDF
/
Inventory: 1337
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Number of Pins 16
Technical
Operating Temperature -55°C~125°C TA
Packaging Cut Tape (CT)
Series 74VHC
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Type D-Type
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory FF/Latches
Packing Method TAPE AND REEL
Technology CMOS
Voltage - Supply 2V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 74VHC174
Function Master Reset
Output Type Non-Inverted
Number of Elements 1
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2/5.5V
Supply Voltage-Min (Vsup) 2V
Number of Circuits 7
Load Capacitance 50pF
Number of Bits 6
Clock Frequency 120MHz
Propagation Delay 14.5 ns
Turn On Delay Time 5.5 ns
Family AHC/VHC
Logic Function D-Type, Flip-Flop
Current - Quiescent (Iq) 4μA
Current - Output High, Low 8mA 8mA
Max I(ol) 0.008 A
Trigger Type Positive Edge
Input Capacitance 6pF
Number of Output Lines 6
Clock Edge Trigger Type Positive Edge
Max Frequency@Nom-Sup 80000000Hz
Dimensions
Length 5mm
Width 4.4mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
