74LVX374MTR
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tape & Reel (TR) 74LVX374 e4 74LVX flip flop 2.65mm 2V 14.1ns @ 3.3V 50pF 95MHz
PDF
/
Inventory: 1651
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7.5mm
Height Seated (Max) 2.65mm
Technical
Max Frequency@Nom-Sup 50000000Hz
Clock Edge Trigger Type Positive Edge
Number of Input Lines 3
Input Capacitance 4pF
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 14.1ns @ 3.3V, 50pF
Max I(ol) 0.004 A
Current - Output High, Low 4mA 4mA
Current - Quiescent (Iq) 4μA
Logic Function D-Type, Flip-Flop
Family LV/LV-A/LVX/H
Turn On Delay Time 9.2 ns
Propagation Delay 19.8 ns
Clock Frequency 95MHz
Number of Bits 8
Number of Ports 2
Load Capacitance 50pF
Number of Circuits 8
Supply Voltage-Min (Vsup) 2V
Polarity Non-Inverting
Number of Elements 1
Output Type Tri-State, Non-Inverted
Function Standard
Base Part Number 74LVX374
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 2.7V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~3.6V
Technology CMOS
Packing Method TAPE AND REEL
Subcategory FF/Latches
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type D-Type
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series 74LVX
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C TA
Physical
Number of Pins 20
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
