SN74AUC1G80YEAR
RoHS
/
Package 5-XFBGA, DSBGA
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
COMMERCIAL Standard D-Type CMOS Flip Flop -40C~85C TA 10muA 2.5pF 0.8V~2.7V
PDF
/
Buying Options
Total Price: USD $0.22
Unit Price: USD $0.22
≥1 USD $0.22
Inventory: 1249
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 0.9mm
Height Seated (Max) 0.5mm
Technical
fmax-Min 275 MHz
Propagation Delay (tpd) 3.9 ns
Input Capacitance 2.5pF
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 1.8ns @ 2.5V, 30pF
Current - Output High, Low 9mA 9mA
Output Characteristics 3-STATE
Current - Quiescent (Iq) 10μA
Family AUC
Clock Frequency 275MHz
Number of Bits 1
Supply Voltage-Min (Vsup) 0.8V
Supply Voltage-Max (Vsup) 2.7V
Number of Elements 1
Output Type Inverted
Qualification Status COMMERCIAL
Function Standard
JESD-30 Code R-XBGA-B5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 1.2V
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 0.8V~2.7V
Technology CMOS
Terminal Finish TIN LEAD
Type D-Type
Number of Terminations 5
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Series 74AUC
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 5-XFBGA, DSBGA
Mounting Type Surface Mount
