MC74HC574AFG
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
BUS DRIVER
PDF
/
Inventory: 1333
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Input Capacitance 10pF
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 27ns @ 6V, 50pF
Number of Bits per Element 8
Current - Output High, Low 7.8mA 7.8mA
Current - Quiescent (Iq) 4μA
Clock Frequency 35MHz
Number of Elements 1
Output Type Tri-State, Non-Inverted
Function Standard
Voltage - Supply 2V~6V
Type D-Type
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series 74HC
Packaging Tube
Operating Temperature -55°C~125°C TA
Physical
Supplier Device Package SOEIAJ-20
Package / Case 20-SOIC (0.209, 5.30mm Width)
Mounting Type Surface Mount
