MC10EP29MNG
RoHS
RoHS compliant
RoHS compliantPackage 20-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tube e3 10EP MATTE TIN flip flop 4mm 3V 3GHz 0.5ns
PDF
/
Inventory: 942
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4mm
Length 4mm
Technical
Propagation Delay (tpd) 0.5 ns
Trigger Type Positive, Negative
Number of Bits per Element 1
Output Polarity COMPLEMENTARY
Current - Quiescent (Iq) 57mA
Family 10E
Clock Frequency 3GHz
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 5.5V
Number of Elements 2
Output Type Differential
Qualification Status COMMERCIAL
Function Set(Preset) and Reset
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply -3V~-5.5V
Technology ECL
Additional Feature NECL MODE: VCC = 0V WITH VEE = -3V TO -5.5V
Terminal Finish MATTE TIN
Type D-Type
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series 10EP
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 20-VFQFN Exposed Pad
Mounting Type Surface Mount
