MC100EP131FAR2
RoHS
/
Package 32-LQFP
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
COMPLEMENTARY COMMERCIAL Set(Preset) and Reset D-Type Flip Flop -40C~85C TA 3V~5.5V 0.6ns 3GHz
PDF
/
Buying Options
Total Price: USD $57.58
Unit Price: USD $57.5795
≥1 USD $57.5795
≥10 USD $47.2454
≥100 USD $45.7691
≥500 USD $44.29185
≥1000 USD $42.81555
Inventory: 1121
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7mm
Length 7mm
Technical
Propagation Delay (tpd) 0.6 ns
Trigger Type Positive Edge
Number of Bits per Element 1
Output Polarity COMPLEMENTARY
Clock Frequency 3GHz
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 5.5V
Number of Elements 4
Output Type Differential
Qualification Status COMMERCIAL
Function Set(Preset) and Reset
JESD-30 Code S-PQFP-G32
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.8mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position QUAD
Voltage - Supply 3V~5.5V
Technology ECL
Additional Feature NECL MODE: VCC = 0V WITH VEE = -3V TO -5.5V
Terminal Finish TIN LEAD
Type D-Type
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e0
Series 100EP
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 32-LQFP
Mounting Type Surface Mount
