CD74HC109M
RoHS
/
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tube 74HC HC/UH Obsolete flip flop 9.9mm 2V 30ns @ 6V 50pF 60MHz
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5456
≥1 USD $0.5456
Inventory: 1100
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -55°C~125°C TA
Packaging Tube
Series 74HC
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Type JK Type
Technology CMOS
Voltage - Supply 2V~6V
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 5V
Function Set(Preset) and Reset
Qualification Status Not Qualified
Output Type Differential
Number of Elements 2
Supply Voltage-Max (Vsup) 6V
Supply Voltage-Min (Vsup) 2V
Clock Frequency 60MHz
Family HC/UH
Current - Quiescent (Iq) 4μA
Current - Output High, Low 5.2mA 5.2mA
Output Polarity COMPLEMENTARY
Number of Bits per Element 1
Max Propagation Delay @ V, Max CL 30ns @ 6V, 50pF
Trigger Type Positive Edge
Input Capacitance 10pF
fmax-Min 60 MHz
Dimensions
Length 9.9mm
Width 3.9mm
Compliance
RoHS Status Non-RoHS Compliant
