CD74ACT174M
RoHS
/
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
TRUE COMMERCIAL Master Reset D-Type Flip Flop -55C~125C TA 8muA 10pF 4.5V~5.5V
PDF
/
Buying Options
Total Price: USD $0.59
Unit Price: USD $0.5896
≥1 USD $0.5896
Inventory: 1017
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -55°C~125°C TA
Packaging Tube
Series 74ACT
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Type D-Type
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 5V
Function Master Reset
Qualification Status COMMERCIAL
Output Type Non-Inverted
Number of Elements 1
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Clock Frequency 80MHz
Family ACT
Current - Quiescent (Iq) 8μA
Current - Output High, Low 24mA 24mA
Output Polarity TRUE
Number of Bits per Element 6
Max Propagation Delay @ V, Max CL 14ns @ 5V, 50pF
Trigger Type Positive Edge
Input Capacitance 10pF
Compliance
RoHS Status Non-RoHS Compliant
