74ACT74MTC
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tube e3 74ACT MATTE TIN flip flop 5mm 4.5V 11ns @ 5V 50pF 210MHz
PDF
/
Buying Options
Total Price: USD $0.28
Unit Price: USD $0.27645
≥1 USD $0.27645
≥10 USD $0.22705
≥100 USD $0.2204
≥500 USD $0.2128
≥1000 USD $0.20615
Inventory: 1277
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series 74ACT
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Type D-Type
Terminal Finish MATTE TIN
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.65mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Function Set(Preset) and Reset
Qualification Status Not Qualified
Output Type Differential
Number of Elements 2
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Clock Frequency 210MHz
Family ACT
Current - Quiescent (Iq) 20μA
Current - Output High, Low 24mA 24mA
Output Polarity COMPLEMENTARY
Number of Bits per Element 1
Max Propagation Delay @ V, Max CL 11ns @ 5V, 50pF
Trigger Type Positive Edge
Input Capacitance 4.5pF
Dimensions
Length 5mm
Width 4.4mm
Compliance
RoHS Status ROHS3 Compliant
