74ACT109SCX
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tape & Reel (TR) e3 74ACT MATTE TIN flip flop 9.9mm 4.5V 11ns @ 5V 50pF 210MHz
PDF
/
Buying Options
Total Price: USD $0.18
Unit Price: USD $0.1848
≥1 USD $0.1848
Inventory: 32764
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 9.9mm
Technical
Input Capacitance 4.5pF
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 11ns @ 5V, 50pF
Number of Bits per Element 1
Output Polarity COMPLEMENTARY
Current - Output High, Low 24mA 24mA
Current - Quiescent (Iq) 20μA
Family ACT
Clock Frequency 210MHz
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
Number of Elements 2
Output Type Differential
Qualification Status Not Qualified
Function Set(Preset) and Reset
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Terminal Finish MATTE TIN
Type JK Type
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series 74ACT
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
