74AC574SCX
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tape & Reel (TR) e3 74AC MATTE TIN flip flop 2.642mm 2V 9.5ns @ 5V 50pF 153MHz
PDF
/
Buying Options
Total Price: USD $0.28
Unit Price: USD $0.2818
≥1 USD $0.2818
≥200 USD $0.109063
≥500 USD $0.105229
≥1000 USD $0.103338
Inventory: 1493
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Height Seated (Max) 2.642mm
Technical
Input Capacitance 4.5pF
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 9.5ns @ 5V, 50pF
Number of Bits per Element 8
Output Polarity TRUE
Current - Output High, Low 24mA 24mA
Output Characteristics 3-STATE
Current - Quiescent (Iq) 40μA
Family AC
Clock Frequency 153MHz
Number of Ports 2
Supply Voltage-Min (Vsup) 2V
Supply Voltage-Max (Vsup) 6V
Number of Elements 1
Output Type Tri-State, Non-Inverted
Qualification Status Not Qualified
Function Standard
JESD-30 Code R-PDSO-G20
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Additional Feature BROADSIDE VERSION OF 374
Terminal Finish MATTE TIN
Type D-Type
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series 74AC
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
