MC74VHC74DR2
RoHS
/
Package 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Contains Lead Not Qualified Set(Preset) and Reset D-Type Flip Flop -55C~125C TA 2muA 4pF 2V~5.5V
PDF
/
Buying Options
Total Price: USD $2.5
Unit Price: USD $2.49755
≥1 USD $2.49755
≥10 USD $2.04915
≥100 USD $1.9855
≥500 USD $1.92185
≥1000 USD $1.85725
Inventory: 4200
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Number of Pins 14
Technical
Operating Temperature -55°C~125°C TA
Packaging Tape & Reel (TR)
Published 2008
Series 74VHC
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Type D-Type
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory FF/Latches
Packing Method TAPE AND REEL
Technology CMOS
Voltage - Supply 2V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Max Frequency@Nom-Sup 75000000Hz
Clock Edge Trigger Type Positive Edge
Number of Output Lines 1
Input Capacitance 4pF
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 9.3ns @ 5V, 50pF
Number of Bits per Element 1
Max I(ol) 0.008 A
Current - Output High, Low 8mA 8mA
Current - Quiescent (Iq) 2μA
Logic Function AND, D-Type, Flip-Flop
Family AHC/VHC
Turn On Delay Time 7.3 ns
Propagation Delay 15.4 ns
Clock Frequency 115MHz
Load Capacitance 50pF
Number of Circuits 2
Supply Voltage-Min (Vsup) 2V
Supply Voltage-Max (Vsup) 5.5V
Polarity Non-Inverting
Output Type Differential
Qualification Status Not Qualified
Function Set(Preset) and Reset
Base Part Number 74VHC74
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 240
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.9mm
Length 8.65mm
