MC74HCT273ADTR2
RoHS
/
Package 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tape & Reel (TR) 74HCT273 e4 74HCT flip flop 0.635mm 25ns @ 5V 50pF 30MHz 25ns
PDF
/
Inventory: 1615
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Clock Edge Trigger Type Positive Edge
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 25ns @ 5V, 50pF
Max I(ol) 0.004 A
Current - Output High, Low 4mA 4mA
Current - Quiescent (Iq) 4μA
Logic Function D-Type, Flip-Flop
Turn On Delay Time 25 ns
Propagation Delay 25 ns
Clock Frequency 30MHz
Load Capacitance 50pF
Number of Circuits 8
Power Supplies 5V
Polarity Non-Inverting
Number of Elements 1
Operating Supply Voltage 5V
Output Type Non-Inverted
Qualification Status Not Qualified
Function Reset
Base Part Number 74HCT273
Terminal Pitch 0.635mm
Supply Voltage 5V
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Packing Method TAPE AND REEL
Subcategory FF/Latches
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type D-Type
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series 74HCT
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C TA
Physical
Number of Pins 20
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
