MC74HC377ADWG
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tube 74HC377 e3 74HC flip flop 2.65mm 2V 27ns @ 6V 50pF 35MHz
PDF
/
Buying Options
Total Price: USD $0.17
Unit Price: USD $0.171728
≥1 USD $0.171728
≥10 USD $0.138773
≥30 USD $0.124647
≥100 USD $0.107015
≥500 USD $0.099176
≥1000 USD $0.094463
Inventory: 3520
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Number of Pins 20
Technical
Operating Temperature -55°C~125°C TA
Packaging Tube
Published 2005
Series 74HC
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
Type D-Type
Terminal Finish Tin (Sn)
Subcategory FF/Latches
Packing Method RAIL
Technology CMOS
Voltage - Supply 2V~6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74HC377
Function Standard
Qualification Status Not Qualified
Output Type Non-Inverted
Number of Elements 1
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 6V
Power Supplies 2/6V
Supply Voltage-Min (Vsup) 2V
Number of Bits 8
Clock Frequency 35MHz
Propagation Delay 1.5 ns
Turn On Delay Time 27 ns
Family HC/UH
Logic Function D-Type, Flip-Flop
Current - Quiescent (Iq) 4μA
Halogen Free Halogen Free
Current - Output High, Low 5.2mA 5.2mA
Max I(ol) 0.004 A
Max Propagation Delay @ V, Max CL 27ns @ 6V, 50pF
Trigger Type Positive Edge
Input Capacitance 10pF
Number of Input Lines 8
Clock Edge Trigger Type Positive Edge
Dimensions
Height Seated (Max) 2.65mm
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
