MC74HC175AD
RoHS
/
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Contains Lead Not Qualified Master Reset D-Type Flip Flop -55C~125C TA 4muA 10pF 2V~6V
PDF
/
Buying Options
Total Price: USD $2.9
Unit Price: USD $2.90225
≥1 USD $2.90225
≥10 USD $2.38165
≥100 USD $2.30755
≥500 USD $2.2325
≥1000 USD $2.1584
Inventory: 2275
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Technical
Operating Temperature -55°C~125°C TA
Packaging Tube
Published 2005
Series 74HC
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Type D-Type
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory FF/Latches
Packing Method RAIL
Technology CMOS
Voltage - Supply 2V~6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Supply Voltage 3V
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number 74HC175
Function Master Reset
Qualification Status Not Qualified
Output Type Differential
Number of Elements 1
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 6V
Power Supplies 2/6V
Supply Voltage-Min (Vsup) 2V
Number of Circuits 4
Load Capacitance 50pF
Number of Bits 4
Clock Frequency 35MHz
Propagation Delay 150 ns
Turn On Delay Time 28 ns
Family HC/UH
Logic Function D-Type, Flip-Flop
Current - Quiescent (Iq) 4μA
Current - Output High, Low 5.2mA 5.2mA
Max Propagation Delay @ V, Max CL 22ns @ 6V, 50pF
Trigger Type Positive Edge
Input Capacitance 10pF
Clock Edge Trigger Type Positive Edge
Max Frequency@Nom-Sup 20000000Hz
Dimensions
Length 9.9mm
Width 3.9mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
