MC74ACT377NG
RoHS
/
Package 20-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Lead Free Standard D-Type CMOS Flip Flop -40C~85C TA 8muA 4.5pF 4.5V~5.5V
PDF
/
Buying Options
Total Price: USD $0.52
Unit Price: USD $0.5192
≥1 USD $0.5192
Inventory: 11889
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 7.62mm
Height Seated (Max) 4.57mm
Technical
Clock Edge Trigger Type Positive Edge
Input Capacitance 4.5pF
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 10ns @ 5V, 50pF
Max I(ol) 0.024 A
Current - Output High, Low 24mA 24mA
Current - Quiescent (Iq) 8μA
Logic Function D-Type, Flip-Flop
Family ACT
Turn On Delay Time 3 ns
Propagation Delay 10 ns
Clock Frequency 140MHz
Number of Bits 8
Load Capacitance 50pF
Number of Circuits 8
Power Supplies 5V
Polarity Non-Inverting
Number of Elements 1
Operating Supply Voltage 5V
Output Type Non-Inverted
Function Standard
Base Part Number 74ACT377
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 2.54mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Subcategory FF/Latches
Terminal Finish Tin (Sn)
Type D-Type
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series 74ACT
Published 2006
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 20
Package / Case 20-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
