MC74AC273DTR2G
RoHS
RoHS compliant
RoHS compliantPackage 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tape & Reel (TR) 74AC273 e4 74AC flip flop 6.6mm 2V 9ns @ 5V 50pF 175MHz
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.7656
≥1 USD $0.7656
≥10 USD $0.68288
≥100 USD $0.648384
≥500 USD $0.497992
≥1000 USD $0.44007
≥3000 USD $0.416926
Inventory: 4168
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4.5mm
Length 6.6mm
Height 1.05mm
Technical
Max Frequency@Nom-Sup 75000000Hz
Clock Edge Trigger Type Positive Edge
Input Capacitance 4.5pF
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 9ns @ 5V, 50pF
Current - Output High, Low 24mA 24mA
Halogen Free Halogen Free
Logic Function D-Type, Flip-Flop
Family AC
Turn On Delay Time 5.5 ns
Quiescent Current 8μA
Propagation Delay 14.5 ns
Clock Frequency 175MHz
Number of Bits 8
Load Capacitance 50pF
Number of Circuits 8
Supply Voltage-Min (Vsup) 2V
Supply Voltage-Max (Vsup) 6V
Polarity Non-Inverting
Number of Elements 1
Operating Supply Voltage 5V
Output Type Non-Inverted
Function Master Reset
Base Part Number 74AC273
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Packing Method TAPE AND REEL
Subcategory FF/Latches
Type D-Type
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74AC
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 20
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
