MC10EP52DTR2G
RoHS
/
Package 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Lead Free Not Qualified Standard D-Type Flip Flop -40C~85C TA 45mA -3V~-5.5V 380ps
PDF
/
Buying Options
Total Price: USD $4.97
Unit Price: USD $4.974335
≥1 USD $4.974335
≥10 USD $4.692763
≥100 USD $4.427138
≥500 USD $4.176542
≥1000 USD $3.940136
Inventory: 4866
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 3mm
Length 3mm
Technical
Max Frequency@Nom-Sup 4000000000Hz
Clock Edge Trigger Type Positive Edge
Power Supply Current-Max (ICC) 47mA
Low Level Output Current 50mA
High Level Output Current -50mA
Trigger Type Positive, Negative
Halogen Free Halogen Free
Current - Quiescent (Iq) 45mA
Logic Function D-Type, Flip-Flop
Family 10E
Turn On Delay Time 330 ps
Propagation Delay 380 ps
Clock Frequency 3GHz
Number of Bits 1
Number of Circuits 1
Supply Voltage-Min (Vsup) 3V
Power Supplies -5.2V
Supply Voltage-Max (Vsup) 5.5V
Polarity Non-Inverting
Output Type Differential
Qualification Status Not Qualified
Function Standard
Base Part Number 10EP52
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply -3V~-5.5V
Technology ECL
Packing Method TAPE AND REEL
Subcategory FF/Latches
Additional Feature NECL MODE: VCC = 0V WITH VEE = -3V TO -5.5V
Terminal Finish Tin (Sn)
Type D-Type
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series 10EP
Published 2000
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
