MC10EP29MNTXG
RoHS
/
Package 20-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tape & Reel (TR) 10EP29 e3 10EP flip flop 4mm 3V 3GHz 500ps
PDF
/
Inventory: 1148
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-VFQFN Exposed Pad
Number of Pins 20
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2009
Series 10EP
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Type D-Type
Terminal Finish Tin (Sn)
Additional Feature NECL MODE: VCC = 0V WITH VEE = -3V TO -5.5V
Subcategory FF/Latches
Technology ECL
Voltage - Supply -3V~-5.5V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 10EP29
Function Set(Preset) and Reset
Qualification Status Not Qualified
Output Type Differential
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 3V
Number of Circuits 2
Clock Frequency 3GHz
Propagation Delay 500 ps
Turn On Delay Time 420 ps
Family 10E
Logic Function AND
Current - Quiescent (Iq) 57mA
Halogen Free Halogen Free
Number of Bits per Element 1
Trigger Type Positive, Negative
High Level Output Current -50mA
Low Level Output Current 50mA
Power Supply Current-Max (ICC) 60mA
Number of Output Lines 1
Clock Edge Trigger Type Positive Edge
Dimensions
Length 4mm
Width 4mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
