MC10E451FNR2
RoHS
/
Package 28-LCC (J-Lead)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tape & Reel (TR) 10E451 e0 10E flip flop 4.57mm 1.1GHz 1.05ns -4.2V~-5.7V
PDF
/
Buying Options
Total Price: USD $7.62
Unit Price: USD $7.6228
≥1 USD $7.6228
≥10 USD $6.2548
≥100 USD $6.0591
≥500 USD $5.8634
≥1000 USD $5.66865
Inventory: 30009
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Height Seated (Max) 4.57mm
Technical
Clock Edge Trigger Type Positive Edge
Low Level Output Current 50mA
High Level Output Current 50mA
Trigger Type Positive Edge
Number of Bits per Element 6
Output Characteristics OPEN-EMITTER
Current - Quiescent (Iq) 101mA
Family 10E
Turn On Delay Time 625 ps
Propagation Delay 1.05 ns
Clock Frequency 1.1GHz
Number of Circuits 2
Supply Voltage-Max (Vsup) 5.7V
Polarity Non-Inverting
Number of Elements 1
Output Type Non-Inverted
Qualification Status Not Qualified
Function Master Reset
Base Part Number 10E451
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Supply Voltage 5V
Peak Reflow Temperature (Cel) 240
Terminal Form J BEND
Terminal Position QUAD
Voltage - Supply -4.2V~-5.7V
Technology ECL
Packing Method TAPE AND REEL
Subcategory FF/Latches
Terminal Finish Tin/Lead (Sn/Pb)
Type D-Type
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e0
Series 10E
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature 0°C~85°C TA
Physical
Number of Pins 28
Package / Case 28-LCC (J-Lead)
Mounting Type Surface Mount
Mount Surface Mount
