MC100EL51DT
RoHS
/
Package 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tube 100EL51 e0 100EL flip flop 3mm 4.2V 2.8GHz 0.62ns
PDF
/
Inventory: 1191
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 3mm
Length 3mm
Technical
Clock Edge Trigger Type Positive Edge
fmax-Min 2200 MHz
Power Supply Current-Max (ICC) 36mA
Low Level Output Current 50mA
High Level Output Current 50mA
Trigger Type Positive, Negative
Prop. Delay@Nom-Sup 0.62 ns
Current - Quiescent (Iq) 29mA
Logic Function Flip-Flop
Turn On Delay Time 475 ps
Propagation Delay 565 ps
Clock Frequency 2.8GHz
Number of Bits 1
Number of Circuits 1
Supply Voltage-Min (Vsup) 4.2V
Power Supplies -4.5V
Supply Voltage-Max (Vsup) 5.7V
Polarity Non-Inverting
Output Type Differential
Qualification Status Not Qualified
Function Reset
Base Part Number 100EL51
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Terminal Pitch 0.65mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply -4.2V~-5.7V
Technology ECL
Packing Method RAIL
Subcategory FF/Latches
Additional Feature NECL MODE: VCC = 0V WITH VEE = -4.2V TO -5.7V
Type D-Type
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Series 100EL
Published 2008
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
