MC100E151FN
RoHS
/
Package 28-LCC (J-Lead)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Contains Lead Not Qualified Master Reset D-Type Flip Flop 0C~85C TA 78mA -4.2V~-5.7V 900ps
PDF
/
Buying Options
Total Price: USD $7
Unit Price: USD $6.996
≥1 USD $6.996
Inventory: 4195
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-LCC (J-Lead)
Number of Pins 28
Technical
Operating Temperature 0°C~85°C TA
Packaging Tube
Published 1996
Series 100E
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 28
Type D-Type
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory FF/Latches
Technology ECL
Voltage - Supply -4.2V~-5.7V
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 240
Supply Voltage 5V
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number 100E151
Function Master Reset
Qualification Status Not Qualified
Output Type Differential
Number of Elements 1
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 5.7V
Power Supplies -4.5V
Number of Circuits 2
Clock Frequency 1.1GHz
Propagation Delay 900 ps
Current - Quiescent (Iq) 78mA
Output Characteristics OPEN-EMITTER
Number of Bits per Element 6
Trigger Type Positive Edge
Power Supply Current-Max (ICC) 90mA
fmax-Min 900 MHz
Clock Edge Trigger Type Positive Edge
Dimensions
Height Seated (Max) 4.57mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
