74ACTQ821SPC
RoHS
/
Package 24-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Lead Free Standard D-Type Positive Edge Flip Flop -40C~85C TA 80muA 4.5pF 4.5V~5.5V
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.924
≥1 USD $0.924
Inventory: 2087
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Clock Edge Trigger Type Positive Edge
Number of Output Lines 3
Input Capacitance 4.5pF
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 9.5ns @ 5V, 50pF
Current - Output High, Low 24mA 24mA
Current - Quiescent (Iq) 80μA
Logic Function D-Type, Flip-Flop
Turn On Delay Time 6.5 ns
Propagation Delay 9.5 ns
Clock Frequency 120MHz
Number of Circuits 10
Polarity Non-Inverting
Number of Elements 1
Operating Supply Voltage 5V
Output Type Tri-State, Non-Inverted
Function Standard
Base Part Number 74ACTQ821
Voltage - Supply 4.5V~5.5V
Type D-Type
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series 74ACTQ
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 24
Package / Case 24-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
