74ACTQ74SJ
RoHS
/
Package 14-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Lead Free Set(Preset) and Reset D-Type Positive Edge Flip Flop -40C~85C TA 20muA 4.5pF 4.5V~5.5V
PDF
/
Buying Options
Total Price: USD $0.32
Unit Price: USD $0.3168
≥1 USD $0.3168
Inventory: 2139
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.209, 5.30mm Width)
Number of Pins 14
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series 74ACTQ
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type D-Type
Voltage - Supply 4.5V~5.5V
Base Part Number 74ACTQ74
Function Set(Preset) and Reset
Output Type Differential
Operating Supply Voltage 5V
Number of Elements 2
Polarity Non-Inverting
Clock Frequency 200MHz
Propagation Delay 8 ns
Turn On Delay Time 7 ns
Logic Function AND, D-Type, Flip-Flop
Current - Quiescent (Iq) 20μA
Current - Output High, Low 24mA 24mA
Max Propagation Delay @ V, Max CL 8ns @ 5V, 50pF
Trigger Type Positive Edge
Input Capacitance 4.5pF
Number of Input Lines 1
Clock Edge Trigger Type Positive Edge
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
