SN74V3640-15PEU
RoHS
RoHS compliant
RoHS compliantPackage 128-LQFP
Category Integrated Circuits (ICs) / Logic - FIFOs Memory
Description
74V3640 Depth Width Tray 74V fifo memory 66.7MHz 40mA 0.5mm 15ns
PDF
/
Buying Options
Total Price: USD $22.92
Unit Price: USD $22.922209
≥1 USD $22.922209
≥10 USD $21.624725
≥100 USD $20.400684
≥500 USD $19.245931
≥1000 USD $18.156536
Inventory: 1355
Minimum: 1
-
+
Technical Details
Technical
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74V3640
Function Synchronous
Current - Supply (Max) 40mA
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 3.45V
Power Supplies 3.3V
Supply Voltage-Min (Vsup) 3.15V
Number of Circuits 2
Memory Size 36K 1K x 36
Access Time 10ns
Data Bus Width 36b
Direction Unidirectional
Organization 1KX36
Memory Width 36
Memory Density 36864 bit
Parallel/Serial PARALLEL
Memory IC Type OTHER FIFO
Bus Directional Uni-Directional
FWFT Support Yes
Output Enable YES
Expansion Type Depth, Width
Cycle Time 15 ns
Frequency 66.7MHz
Reach Compliance Code not_compliant
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position QUAD
Voltage - Supply 3.15V~3.45V
Technology CMOS
Subcategory FIFOs
ECCN Code EAR99
Number of Terminations 128
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series 74V
Packaging Tray
Operating Temperature 0°C~70°C
Dimensions
Height Seated (Max) 1.6mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
Physical
Number of Pins 128
Package / Case 128-LQFP
Mounting Type Surface Mount
Mount Surface Mount
