SN74ACT7882-20PN
RoHS
RoHS compliant
RoHS compliantPackage 80-LQFP
Category Integrated Circuits (ICs) / Logic - FIFOs Memory
Description
QUAD PARALLEL GULL WING Synchronous Synchronous FIFO 0C~70C 5.5V 36K 2K x 18 50MHz
PDF
/
Inventory: 3163
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 12mm
Length 12mm
Height Seated (Max) 1.6mm
Technical
Cycle Time 20 ns
Expansion Type Depth, Width
Output Enable YES
Programmable Flags Support Yes
Retransmit Capability No
Bus Directional Uni-Directional
Parallel/Serial PARALLEL
Memory Density 36864 bit
Memory Width 18
Organization 2KX18
Data Rate 50MHz
Access Time 13ns
Memory Size 36K 2K x 18
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status COMMERCIAL
Current - Supply (Max) 400μA
Function Synchronous
JESD-30 Code S-PQFP-G80
Terminal Pitch 0.5mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Voltage - Supply 4.5V~5.5V
Technology CMOS
Terminal Finish NICKEL PALLADIUM GOLD
Number of Terminations 80
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series 74ACT
Packaging Tray
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 80-LQFP
Mounting Type Surface Mount
