SN74ACT7882-15PN

Rochester Electronics, LLC
RoHS
RoHS RoHS compliant
Package 80-LQFP
Category Integrated Circuits (ICs) / Logic - FIFOs Memory
Description QUAD PARALLEL GULL WING Synchronous Synchronous FIFO 0C~70C 5.5V 36K 2K x 18 67MHz
PDF
/
Buying Options
Total Price: USD $139.42
Unit Price: USD $139.422
≥1 USD $139.422
≥10 USD $134.7746
≥100 USD $120.8324
Inventory: 908
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 12mm
Length 12mm
Height Seated (Max) 1.6mm

Technical

Cycle Time 15 ns
Expansion Type Depth, Width
Output Enable YES
Programmable Flags Support Yes
Retransmit Capability No
Bus Directional Uni-Directional
Parallel/Serial PARALLEL
Memory Density 36864 bit
Memory Width 18
Organization 2KX18
Data Rate 67MHz
Access Time 12ns
Memory Size 36K 2K x 18
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status COMMERCIAL
Current - Supply (Max) 400μA
Function Synchronous
JESD-30 Code S-PQFP-G80
Terminal Pitch 0.5mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Voltage - Supply 4.5V~5.5V
Technology CMOS
Terminal Finish NICKEL PALLADIUM GOLD
Number of Terminations 80
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series 74ACT
Packaging Tray
Operating Temperature 0°C~70°C

Physical

Surface Mount YES
Package / Case 80-LQFP
Mounting Type Surface Mount
