SN74ACT7804-20DLR
RoHS
RoHS compliant
RoHS compliantPackage 56-BSSOP (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - FIFOs Memory
Description
DUAL PARALLEL GULL WING Asynchronous Asynchronous FIFO 0C~70C 5.5V 9K 512x 18 50MHz
PDF
/
Buying Options
Total Price: USD $6.17
Unit Price: USD $6.175
≥1 USD $6.175
≥10 USD $5.0673
≥100 USD $4.90865
≥500 USD $4.75
≥1000 USD $4.5923
Inventory: 947
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 56-BSSOP (0.295, 7.50mm Width)
Surface Mount YES
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
Series 74ACT
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 56
Terminal Finish NICKEL PALLADIUM GOLD
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.635mm
JESD-30 Code R-PDSO-G56
Function Asynchronous
Current - Supply (Max) 400μA
Qualification Status COMMERCIAL
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Memory Size 9K 512 x 18
Access Time 15ns
Data Rate 50MHz
Organization 512X18
Memory Width 18
Memory Density 9216 bit
Parallel/Serial PARALLEL
Bus Directional Uni-Directional
Retransmit Capability No
Programmable Flags Support Yes
Output Enable YES
Expansion Type Width
Cycle Time 20 ns
Dimensions
Height Seated (Max) 2.79mm
Length 18.415mm
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
