SN74ACT2235-60PAG
RoHS
RoHS compliant
RoHS compliantPackage 64-TQFP
Category Integrated Circuits (ICs) / Logic - FIFOs Memory
Description
QUAD PARALLEL GULL WING Asynchronous Asynchronous FIFO 0C~70C 5.5V 18K 1K x 9x 2 16.7MHz
PDF
/
Inventory: 910
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 64-TQFP
Surface Mount YES
Technical
Operating Temperature 0°C~70°C
Packaging Tray
Series 74ACT
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Terminal Finish NICKEL PALLADIUM GOLD
Additional Feature BYPASS-XCVR
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.5mm
JESD-30 Code S-PQFP-G64
Function Asynchronous
Current - Supply (Max) 400μA
Qualification Status COMMERCIAL
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Memory Size 18K 1K x 9 x 2
Access Time 45ns
Data Rate 16.7MHz
Organization 1KX9
Memory Width 9
Memory Density 9216 bit
Parallel/Serial PARALLEL
Bus Directional Bi-Directional
Retransmit Capability No
Programmable Flags Support Yes
Output Enable YES
Cycle Time 60 ns
Dimensions
Height Seated (Max) 1.2mm
Length 10mm
Width 10mm
Compliance
RoHS Status ROHS3 Compliant
