SN74ABT3612-30PCB
RoHS
RoHS compliant
RoHS compliantPackage 120-LQFP Exposed Pad
Category Integrated Circuits (ICs) / Logic - FIFOs Memory
Description
QUAD PARALLEL GULL WING Synchronous Synchronous FIFO 0C~70C 5.5V 4.5K 64x 36x 2 33.4MHz
PDF
/
Inventory: 8757
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 14mm
Length 14mm
Height Seated (Max) 1.6mm
Technical
Cycle Time 30 ns
Expansion Type Width
Output Enable YES
Programmable Flags Support Yes
Retransmit Capability No
Bus Directional Bi-Directional
Parallel/Serial PARALLEL
Memory Density 2304 bit
Memory Width 36
Organization 64X36
Data Rate 33.4MHz
Access Time 15ns
Memory Size 4.5K 64 x 36 x 2
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status COMMERCIAL
Current - Supply (Max) 130mA
Function Synchronous
JESD-30 Code S-PQFP-G120
Terminal Pitch 0.4mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Voltage - Supply 4.5V~5.5V
Technology BICMOS
Additional Feature PARITY GENERATOR/CHECKER; MAILBOX
Terminal Finish NICKEL PALLADIUM GOLD
Number of Terminations 120
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series 74ABT
Packaging Tray
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 120-LQFP Exposed Pad
Mounting Type Surface Mount
