CY7C4261-15JC
RoHS
/
Package 32-LCC (J-Lead)
Category Integrated Circuits (ICs) / Logic - FIFOs Memory
Description
QUAD PARALLEL J BEND Synchronous Synchronous FIFO 0C~70C 5.5V 144K 16K x 9 66.7MHz
PDF
/
Buying Options
Total Price: USD $13.57
Unit Price: USD $13.5696
≥1 USD $13.5696
Inventory: 268
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 11.43mm
Length 13.97mm
Height Seated (Max) 3.556mm
Technical
Cycle Time 15 ns
Expansion Type Depth, Width
Output Enable YES
Programmable Flags Support Yes
Retransmit Capability No
Bus Directional Uni-Directional
Parallel/Serial PARALLEL
Memory Density 147456 bit
Memory Width 9
Organization 16KX9
Data Rate 66.7MHz
Access Time 10ns
Memory Size 144K 16K x 9
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status COMMERCIAL
Current - Supply (Max) 35mA
Function Synchronous
JESD-30 Code R-PQCC-J32
Terminal Pitch 1.27mm
Supply Voltage 5V
Terminal Form J BEND
Terminal Position QUAD
Voltage - Supply 4.5V~5.5V
Technology CMOS
Additional Feature RETRANSMIT
Terminal Finish TIN LEAD
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Series CY7C
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 32-LCC (J-Lead)
Mounting Type Surface Mount
