72V831L15TF
RoHS
/
Package TQFP
Category Integrated Circuits (ICs) / Logic - FIFOs Memory
Description
QUAD COMMERCIAL Synchronous PARALLEL (Function) FIFO 0C 3.6V 36kb 15ns
PDF
/
Inventory: 1749
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Dimensions
Thickness 1.4mm
Width 10mm
Length 10mm
Height Seated (Max) 1.6mm
Technical
Cycle Time 15 ns
Output Enable YES
Programmable Flags Support Yes
FWFT Support No
Bus Directional Bidirectional
Memory IC Type OTHER FIFO
Word Size 9b
Sync/Async Synchronous
Parallel/Serial PARALLEL
Standby Current-Max 0.01A
Density 36 kb
Organization 2KX9
Access Time 10 ns
Frequency (Max) 66.7MHz
Max Supply Current 40mA
Nominal Supply Current 40mA
Min Supply Voltage 3V
Max Supply Voltage 3.6V
Temperature Grade COMMERCIAL
Operating Supply Voltage 3.3V
Pin Count 64
Time@Peak Reflow Temperature-Max (s) 20
Frequency 66.7MHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory FIFOs
HTS Code 8542.32.00.71
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Tin/Lead (Sn85Pb15)
ECCN Code EAR99
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3
Part Status Discontinued
Pbfree Code no
JESD-609 Code e0
Published 2008
Physical
Number of Pins 64
Package / Case TQFP
Mount Surface Mount
Contact Plating Lead, Tin
